Steel Palisade Corner Fish Plate
£2.00 ex VAT
Out of stock
Product Overview
The Steel Palisade Corner Fish Plate is a galvanised steel connector designed to join horizontal palisade rails where a fencing run changes direction. Its angled profile creates a secure connection between rails meeting at a standard 90-degree corner, helping maintain the correct rail position around commercial, industrial and infrastructure perimeters. It can also allow a compatible standard palisade post to be incorporated at the corner position.
Customers may require corner fish plates when configuring a new system, introducing a return into an existing run or replacing damaged or missing fittings. A conventional two-rail palisade system generally requires one corner plate at the upper rail level and another at the lower rail level. The galvanised finish provides corrosion resistance for exposed outdoor installations, while the bolted connection supports straightforward assembly and future component replacement. This plate is specifically intended for corner positions and should not be used as a substitute for standard straight-run or end fish plates. Compatibility with the post, rails and M12 fixings must be confirmed before installation.
What’s Included
Toggle• 1 x Steel Palisade Corner Fish Plate
You May Also Need
Toggle• 2 x M12 x 35mm Nuts and Bolts
• Compatible steel palisade post
• Steel palisade horizontal rails
• Additional corner fish plate for the second rail level
• Standard or end fish plates for adjoining positions
Key Features
Toggle• Connects horizontal rails at a 90-degree change of direction
• Maintains alignment through palisade fencing corners
• Allows compatible standard posts to be used at corner positions
• Galvanised steel construction provides corrosion resistance
• Suitable for new systems, alterations and replacement work
• Compact bolted connection simplifies installation
• Supports secure assembly with the correct M12 fixings
• Keeps corner components consistent with the adjoining palisade system
Typical Applications
Toggle• Steel palisade perimeter corners
• Commercial premises
• Industrial boundaries
• Utilities and infrastructure
• Warehouses and distribution centres
• Palisade fencing alterations and extensions
Frequently Asked Questions
ToggleQ. How many corner fish plates are required?
A. A conventional system with upper and lower horizontal rails normally requires two corner fish plates – one at each rail level.
Q. Is this plate intended for a 90-degree corner?
A. Yes. It is designed to connect rails at a standard 90-degree change of direction. Bespoke angles may require different or specially fabricated fittings.
Q. Are the required bolts included?
A. No. This listing contains one corner fish plate. Compatible M12 x 35mm nuts and bolts are purchased separately.
Q. Can a standard straight fish plate be used at a corner?
A. No. A standard fish plate aligns rails along a straight run and cannot provide the angled connection required at a corner.
Q. Will it fit every steel palisade system?
A. Compatibility should be checked against the post slots, rail arrangement, plate dimensions, hole positions and required fixing size before ordering.
