Steel Palisade End Fish Plate
£2.00 ex VAT
Out of stock
Product Overview
The Steel Palisade End Fish Plate is a galvanised steel connector used where a horizontal palisade rail terminates at the final post of a fencing run. Its shaped profile secures one rail end rather than joining rails on both sides, creating a supported and properly finished termination. It can also enable a compatible standard palisade post to be used at an end position without requiring a separately manufactured end post.
Customers may require end fish plates when completing a new perimeter, creating an opening, shortening an existing run or replacing missing or damaged fittings. A conventional system with upper and lower horizontal rails normally needs one end plate at each rail level. The galvanised finish provides corrosion resistance for exposed outdoor locations, while the bolted construction supports straightforward installation and future component replacement. This fitting is specifically designed for the termination of a rail and should not be substituted with a standard straight-run or corner fish plate. Compatibility with the post slots, horizontal rails and required M12 fixings must be confirmed before installation.
What’s Included
Toggle• 1 x Steel Palisade End Fish Plate
You May Also Need
Toggle• 2 x M12 x 35mm Nuts and Bolts
• Compatible steel palisade post
• Steel palisade horizontal rails
• Additional end fish plate for the second rail level
• Standard or corner fish plates for other post positions
Key Features
Toggle• Terminates horizontal palisade rails at the final post
• Creates a secure and properly supported end to the fencing run
• Allows compatible standard posts to be used at end positions
• Galvanised steel construction provides corrosion resistance
• Suitable for new installations, alterations and repairs
• Compact bolted connection simplifies component replacement
• Supports secure assembly with the correct M12 fixings
• Prevents the need to extend a rail beyond the final post
Typical Applications
Toggle• Ends of steel palisade fencing runs
• Gate and access openings
• Commercial premises
• Industrial boundaries
• Utilities and infrastructure
• Palisade fencing alterations and repairs
Frequently Asked Questions
ToggleQ. How many end fish plates are required at an end post?
A. A conventional system with upper and lower horizontal rails normally requires two end fish plates – one at each rail level.
Q. Are the required nuts and bolts included?
A. No. This listing contains one end fish plate. Compatible M12 x 35mm nuts and bolts are purchased separately.
Q. Can this convert a standard post into an end post?
A. It can convert a compatible intermediate palisade post into an end position, provided the post slots, rails and fixings are suitable.
Q. Can a standard fish plate be used at the end of a run?
A. No. A standard fish plate is designed to connect rails on both sides of an intermediate post. An end plate is shaped to terminate a single rail correctly.
Q. Will it fit every steel palisade system?
A. Compatibility should be checked against the post slots, rail arrangement, plate dimensions, fixing-hole positions and required bolt size before ordering.
